X-ray Analysis

The Suib Group has 3 X-ray instruments in-house consisting of a powder X-ray diffractometer, an in-situ X-ray diffractometer, and a X-ray fluorescence spectrometer.

20251124_131923

Our Rigaku Ultima IV powder X-ray diffractometer is utilized mainly for analysis of catalysts, battery, and ceramic powders

20251124_131937

Inner arms of the Rigaku Ultima IV P-XRD.

20251124_131958

Our Rigaku ZSX PrimusIV, which is used for bulk analysis of solid materials. This particular model is a wavelength dispersive (WD) model with the ability to analyze elements from Be to U.

20251124_132925

Our Thermo Fisher ARL in-situ X-ray diffractometer. This instrument is used to study solid materials at different temperatures, this instrument is able to test materials up to 900°C.

20251124_132905

The in-situ cell for our ThermoFisher X-ray diffractometer.
